| Distribution Cable
Application
| ● The Breakout cable can be directly assembled with connectors as pigtail or patch cord. | ||||||||
| ● The link between the communication device and instrument. | ||||||||
| ● As building to building connecting cables. As indoor soft cable along the walls and ceiling and between layers and in ducts. | ||||||||
Features
| ● All of sheath materials are RoHS compliance : PVC，LSZH ( Low Smoke Zero Halogen )，Hytrel，OFNP etc. | ||||||||||
| Both OFNP and OFNR meet UL flame retardant specification. | ||||||||||
|
● Smaller outer diameter and light-weighted. Easy to be deployed. It can effectively overcome the difficulties of the old pipeline construction. |
||||||||||
| ● Storage, installation, operationg temperature : -20℃ ~ +70 ℃ | ||||||||||
Specification
| Fiber Count | Outer Diameter ( mm ) | Weight ( g/m ) | Mini Bending Radius (mm) | Max. Tensile Strength (N) | ||
|---|---|---|---|---|---|---|
| Load | Unload | Short term | Long term | |||
| 6 - 36 | ≦ 15 | ≦ 160 | ≦ 65 | ≦ 45 | ≦ 1800 | ≦ 600 |
